A hobbyist has redesigned a voltmeter clock originally built in 2019, improving its appearance and functionality. The new version uses simpler materials and a more elegant enclosure, with continuous display motion. Details are based on a detailed DIY process shared online.
A hobbyist has unveiled a revised version of a voltmeter clock originally built in 2019, featuring a cleaner design, improved aesthetics, and continuous motion for the hands. The project, shared on Hacker News, highlights a simplified construction process and a focus on visual appeal, making it accessible for DIY enthusiasts.
The new voltmeter clock uses three generic 90° panel voltmeters sourced from Amazon, which were disassembled and customized with printed decals for the dial faces. The design incorporates a continuous motion mechanism, achieved by controlling the duty cycle of digital pulse signals to the meters, eliminating the need for complex analog components.
The enclosure was crafted from maple wood, with a CNC-milled front and back panels. The side walls were bent using a series of internal notches and moisture to achieve a seamless curved shape, then glued and finished with lacquer. The entire process emphasizes simplicity and elegance, contrasting with more complicated previous designs.
The circuit powering the clock is minimal, based on an AVR128DB28 microcontroller. It drives the meters via digital output pins, with two pushbuttons for setting the time. The design avoids digital-to-analog converters, instead relying on pulse-width modulation to control the meter positions, leveraging the inertia of the analog meters for smooth motion.
Why It Matters
This project demonstrates how accessible DIY electronics and woodworking skills can be combined to create functional, aesthetically pleasing timepieces. It offers a low-cost, customizable alternative to traditional clocks, appealing to hobbyists and makers interested in analog displays and microcontroller control.
While primarily a hobbyist project, the approach highlights potential for further customization and integration into personal or artistic timepieces, emphasizing simplicity and elegance over complexity. It also underscores ongoing interest in analog-digital hybrid devices within maker communities.
